Quenched / Tempered Hollow Steel Round Bar With Chrome Plating

Chứng nhận
Trung Quốc Jiangsu New Heyi Machinery Co., Ltd Chứng chỉ
Trung Quốc Jiangsu New Heyi Machinery Co., Ltd Chứng chỉ
Khách hàng đánh giá
Good service, good quality

—— AMMA - Russia

Very good factory

—— Peter-America

Tôi trò chuyện trực tuyến bây giờ

Quenched / Tempered Hollow Steel Round Bar With Chrome Plating

Quenched / Tempered Hollow Steel Round Bar With Chrome Plating
Quenched / Tempered Hollow Steel Round Bar With Chrome Plating Quenched / Tempered Hollow Steel Round Bar With Chrome Plating

Hình ảnh lớn :  Quenched / Tempered Hollow Steel Round Bar With Chrome Plating

Thông tin chi tiết sản phẩm:

Nguồn gốc: China
Hàng hiệu: HY
Chứng nhận: ISO9001:2008

Thanh toán:

Số lượng đặt hàng tối thiểu: 5 tons
Giá bán: Negotiation
chi tiết đóng gói: Anti rust oil to be applied on material and each rod to be packed in paper sleeve
Thời gian giao hàng: 30days
Điều khoản thanh toán: L/C, T/T
Khả năng cung cấp: 30tons a day
Chi tiết sản phẩm
Name: Hollow round bar Raw material: Stainless steel, Carbon steel
Tensile strength: Not less than 610 N/MM2 Yield strength: Not less than 355 N/MM2
Surface condition: Chrome Plating Chrome thickness: 25 +/- 5 micron
Điểm nổi bật:

round hollow bar

,

hollow steel bar

Quenched / Tempered Hollow Steel Round Bar With Chrome Plating


Detailed Product  Description

1. Material: CK45, ST52, 20MnV6, 42CrMo4, 40Cr
2. Diameter: 6mm - 1000mm
3. Length: 1000mm - 8000mm
4. Advanced inspection apparatus
5. Complete manufactured equipment


Detailed Description
1.CHEMICAL COMPOSITION

Material

C%

Mn%

Si%

S%

P%

V%

Cr%

Ck45

0.42-0.50

0.50-0.80

0.04

0.035

0.035





ST52

0.22

1.6

0.55

0.035

0.04





20MnV6

0.16-0.22

1.30-1.70

0.10-0.50

0.035

0.035

0.10-0.20



42CrMo4

0.38-0.45

0.60-0.90

0.15-0.40

0.03

0.03



0.90-1.20

40Cr

0.37-0.45

0.50-0.80

0.17-0.37







0.80-1.10


2.MECHANCIAL PROPERTIES

Material

T.S  N/MM2

Y.S  N/MM2

E%(MIN)

CHARPY

CONDITION

CK45

610

355

15

>41J

NORMALIZE

CK45

800

630

20

>41J

Q + T

ST52

500

355

22



NORMALIZE

20MnV6

750

590

12

>40J

NORMALIZE

42CrMo4

980

850

14

>47J

Q + T

40Cr

1000

800

10



Q + T


3. SUPPLY CONDITION
    Ground  and  chrome plated
4. CHROME THICKNESS
     20 to 30 micron
5. SURFACE ROUGHNESS
     Ra≤0.2 micron and  Rt≤2 micro
6. TOLERANCES ON DIA
    ISO f7 on the diameter
7.OVALITY
Half of the tolerance ISO f7
8. STRAIGHTNESS
   ≤0.2MM/M
9. SURFACE HARDNESS
   850-1150HV (vickers 100g)
10.COHESION
   No cracks,breaking or detaching after thermic shock(warming up at 300 celsius degrees and cooling
   in water)
11 .POROSITY
     Test according to ISO 1456/1458 and result yaluation according to ISO 4540 rating 8-10
12 CORROSION RESISTANCE
     Test in natural salt spray according to ASTM B 117-72hours
     Results evaluation according to ISO 4540 RATING 7-10
13. WELDABILITY
      Good
14. PACKING
     Anti rust oil to be applied on material and each rod to be packed in paper sleeve
15. CERTIFICATE
     All certificate related with material heat treatment and plating is required

Our  Advantage:
(1) We have first-class testing equipment to detect data parameters of chrome piston rod and control the quality of chrome piston rod.
(2) We have our own R & D capabilities, to help customers solve the problem of non-standard customized products.
(3) price, our manufacture ensure that our prices across China are quite competitive.
