Round CK45 Induction Hardened Rod With Chrome Plating Diameter 6mm - 1000mm

Hình ảnh lớn : Round CK45 Induction Hardened Rod With Chrome Plating Diameter 6mm - 1000mm

Thông tin chi tiết sản phẩm:

Place of Origin:	China
Hàng hiệu:	HY
Chứng nhận:	ISO9001:2008

Thanh toán:

Minimum Order Quantity:	5 tons
Giá bán:	Negotiation
Packaging Details:	Anti rust oil to be applied on material and each rod to be packed in paper sleeve
Delivery Time:	30days
Payment Terms:	L/C, T/T
Supply Ability:	30tons a day

Tiếp xúc

Chi tiết sản phẩm

Sản phẩm:	Thanh piston cứng cảm ứng	Điều Kiện Bề MẶT:	Mạ crom cứng
Độ dày của Chrome:	20-30 micron	Độ nhám bề mặt:	Ra≤0,2micron và Rt≤2micro
Noãn sào:	Một nửa dung sai ISO f7	Ngay thẳng:	Không quá 0,2 MM / M
Điểm nổi bật:	thanh thép cứng , thanh thép cứng , thanh cứng cảm ứng ck45 tròn

Round CK45 Induction Hardened Rod With Chrome Plating Diameter 6mm - 1000mm

Detailed Product Description

1. Material: CK45, ST52, 20MnV6, 42CrMo4, 40Cr

2. Diameter: 6mm - 1000mm

3. Length: 1000mm - 8000mm

4. Condition: Chrome plated, Quenched / Tempered, Induction hardened, Q / T Induction hardened

5. Application: Mining machinery industry, textile / printing industry and so on

6. Case depth:1.5mm - 2.5mm Induction hardness:HRC50 - 60

Detailed Description

1.CHEMICAL COMPOSITION

Material	C%	Mn%	Si%	S%	P%	V%	Cr%
Ck45	0.42-0.50	0.50-0.80	0.04	0.035	0.035
ST52	0.22	1.6	0.55	0.035	0.04
20MnV6	0.16-0.22	1.30-1.70	0.10-0.50	0.035	0.035	0.10-0.20
42CrMo4	0.38-0.45	0.60-0.90	0.15-0.40	0.03	0.03		0.90-1.20
40Cr	0.37-0.45	0.50-0.80	0.17-0.37				0.80-1.10

2.MECHANCIAL PROPERTIES

Material	T.S N/MM2	Y.S N/MM2	E%(MIN)	CHARPY	CONDITION
CK45	610	355	15	>41J	NORMALIZE
CK45	800	630	20	>41J	Q + T
ST52	500	355	22		NORMALIZE
20MnV6	750	590	12	>40J	NORMALIZE
42CrMo4	980	850	14	>47J	Q + T
40Cr	1000	800	10		Q + T

3. SUPPLY CONDITION

Ground and chrome plated

4. CHROME THICKNESS

20 to 30 micron

5. SURFACE ROUGHNESS

Ra≤0.2 micron and Rt≤2 micro

6. TOLERANCES ON DIA

ISO f7 on the diameter

7.OVALITY

Half of the tolerance ISO f7

8. STRAIGHTNESS

≤0.2MM/M

9. SURFACE HARDNESS

850-1150HV (vickers 100g)

10.COHESION

No cracks,breaking or detaching after thermic shock(warming up at 300 celsius degrees and cooling

in water)

11 .POROSITY

Test according to ISO 1456/1458 and result yaluation according to ISO 4540 rating 8-10

12 CORROSION RESISTANCE

Test in natural salt spray according to ASTM B 117-72hours

Results evaluation according to ISO 4540 RATING 7-10

13. WELDABILITY

Good

14. PACKING

Anti rust oil to be applied on material and each rod to be packed in paper sleeve

15. CERTIFICATE

All certificate related with material heat treatment and plating is required

We imported one continous chrome plating line from Italy at the beginning of 2016. With this new chrome plating line, we will improve efficiency and product quality a lot.The new chrome plating line is the first one in China and will be the only one in the next five years!
